Stainless Steel Mesh
Supplier in UAE

What is Stainless Steel Wire Mesh

YKM Group, Largest and Best Stainless Steel Mesh Supplier in UAE and SS Mesh Manufacturer manufacture stainless steel wire mesh primarily made of stainless-steel wire through warp and weft woven. YKM, Best Stainless Steel Mesh Supplier in UAE manufacture Steel Wire Mesh that are mainly used for the filtration and screening of gas, liquid and solid, the separation of media and so on. Since these wire meshes are resistant to acid, alkali, high temperature and grind, it is widely used in industries like petroleum, petrochemical, automotive, new energy, food, Pharmaceutical and others.

Largest Manufacturer Of Stainless Steel Wire Mesh
Different Grades of Stainless Steel Wire Mesh

What are the Grades of Stainless-Steel Wire Mesh?

YKM International LLC. Stainless Steel Mesh Supplier in UAE and SS Mesh Manufacturer is capable of manufacturing woven wire mesh of 302 SS, 304 SS, 304L SS, 310 SS, 316 SS, 316L SS, 317L SS, 321 SS, 330 SS, 347 SS, 410 SS, and 430 SS grades and these wire filter mesh cloths are mainly used for the filtration and screening of gas, liquid and solid, the separation of media and so on.

Wire Mesh is sometimes referred to as wire mesh screen is a very popular metal wire filter cloth commonly named based on the opening size and woven pattern



What are the Different Stainless Steel Wire Mesh Weave Pattern?

YKM, Stainless Steel Mesh Supplier in UAE manufactures Stainless Steel Square Wire Mesh in :



  • Plain Weave Wire Mesh
  • Twill Weave Wire Mesh
Stainless Steel Wire Mesh Weaving in YKM Factory
Stainless Steel Dutch Weave Wire Mesh Pattern Manufacturers

Stainless Steel Dutch Weave Wire Mesh



  • Plain Dutch Weave
  • Twill Dutch Weave
  • Double Warp Dutch Weave
  • Reverse Plain Dutch Weave
  • Reverse Twill Dutch Weave

What is Plain Weave Steel Wire mesh?

The Plain Weave Wire Mesh is also called plain weave and is the most used weave.
Plain Weave Wire Mesh from YKM International LLC. is a steel wire that passes alternatively over and under each warp wire, and vice versa. The warp and weft wire diameter is usually the same.

Largest Wire MesH Manufacturer in Bahrain
Twill Weave Stainless Steel Wire Mesh Pattern Manufacturers and Suppliers in Muscat

What is Twill Weave Steel Wire Mesh Pattern?

Twill Weave Wire Mesh from YKM is fabricated bypassing every Metal wire alternately up and down of two warp wires. The Wire Mesh pattern is staggered on following warp wires, providing a parallel diagonal lines appearance. Twill Weave Wire Mesh permits the use of relatively heavier wires in the specific mesh count than is feasible in the plain weave mesh. We, The best Stainless Steel Mesh Supplier in UAE and SS Mesh Manufacturer manufacture Top Notch quality wire mesh filter cloths which plays vital role in industries where the loads are larger and filtration of the finer particle is demanded.

What is Plain Dutch Weave Wire Mesh Pattern?

The Plain Dutch Weave is a type of weave with a greater amount of warp wires than the weft wires. The Plain Dutch Weave Wire Mesh from YKM Group, Best SS Mesh Manufacturer meshes are made up of a limited number of warp wires interwoven with the maximum number of weft wires, thereby producing a stable and strong cloth. The Plain Dutch Weave Wire Mesh has a high filtering capacity and very high-pressure load resistance.

  • Drum filters
  • Nutsche filters
  • Cartridge filters
  • Vertical pressure leaf filters



Plain Dutch Weave Wire Mesh Pattern Manufacturers and Suppliers in Oman
Twill Dutch Weave Wire Mesh Pattern Mesh Manufacturer in Saudi

What is Twill Dutch Weave Wire Mesh Pattern?

Twill Dutch Weave Wire Mesh is similar to Plain Dutch Weave Wire Mesh, except that the weave pattern is twilled, with a double layer of weft wires. There are no apertures in the true sense, and the filtrate follows a sinuous path through the depth of the wire cloth.

What is Reverse Plain Dutch Weave?

In Reverse Plain Dutch Weave Wire Mesh, the mesh pattern is the reverse of Plain Dutch Weave Wire Mesh, i.e., it has more thin warp wires, but larger, weft wires. This structure provides a high degree of stability and optimal resistance to high pressure.

The Reverse Plain Dutch Weave Wire Mesh from YKM international LLC is manufactured with smaller warp wires that are more numerous than the weft wires. The Smaller and closer warp wires combined with the weft wires form triangular-shaped transversal openings.

The reverse Dutch weave wire mesh has a very high level of mechanical load and a high flow and porosity level.

Reverse Plain Dutch Weave Manufacturers in Zohar
Reverse Twill Dutch Weave Manufacturers in Doha

What is Reverse Twill Dutch Weave?

Reverse Twill Dutch Weave Wire Mesh from YKM combines Dutch and Twill weave techniques to produce a fine filtration mesh. The weaving process includes using very fine wires to fabricate filtering metal mesh cloth for liquid and gas applications. The flow rate in these kinds of wire filter mesh is relatively low and is used for filter leaves and regular filtration belts.

Size Chart

SS Square Wire MeshSS Reverse Dutch Weave Wire ClothSS Plain Dutch WeaveSS Twill Dutch WeaveSS Bolt Mesh
Meshes per Linear InchWire diameterWidth of OpeningOpen Area
inchmminchmmpercent
1x10.15740.8421.471
2x20.1182.50.3810.264
3x30.07920.256.458
4x40.0631.60.1874.7556
4x40.0471.190.2035.1665.9
5x50.0551.40.143.6852
6x60.0471.20.123.0351
8x80.431.10.082.0842
10x100.03910.061.5436
10x100.020.510.082.0364
12x120.0230.5840.061.5251.8
12x120.020.5080.0631.657.2
14x140.0230.5840.0481.2245.2
14x140.020.5080.0511.351
16x160.0180.4570.04451.1350.7
18x180.0170.4320.03860.9848.3
20x200.020.5080.030.7636
20x200.0160.4060.0340.8646.2
24x240.0140.3560.02770.744.2
30x300.0130.330.02030.5237.1
30x300.0120.3050.02130.5440.8
30x300.0090.2290.02430.6253.1
35x350.0110.2790.01760.4537.9
40x400.010.2540.0150.3836
50x500.0090.2290.0110.2830.3
50x500.0080.2030.0120.3136
60x600.00750.1910.00920.2330.5
60x600.0070.1780.00970.2533.9
70x700.00650.1650.00780.229.8
80x800.00650.1650.0060.1523
80x800.00550.140.0070.1831.4
90x900.0050.1270.00610.1630.1
100x1000.00450.1140.00550.1430.3
100x1000.0040.1020.0060.1536
100x1000.00350.0890.00650.1742.3
110x1100.0040.10160.00510.129530.7
120x1200.00370.0940.00460.116830.7
150x1500.00260.0060.00410.104137.4
160x1600.00250.06350.00380.096536.4
180x1800.00230.05840.00330.083834.7
200x2000.00210.05330.00290.073733.6
250x2500.00160.04060.00240.06136
270x2700.00160.04060.00210.053332.2
300x3000.00150.03810.00180.045729.7
325x3250.00140.03560.00170.043230
400x4000.0010.02540.00150.03736
500x5000.0010.02540.0010.025425
635x6350.00080.02030.00080.020325
YKM-CodeWire Diameter(um)Micron Retention(um)ProsityWeightCloth
MeshTheor(kg/m2)Thickness
WarpWeftNominalAbsolute(%)(mm)
RFD40084x14---450-530623.51.15
RFD125260x40--125112-125542.250.62
RFD90170x40--90106-118542.10.57
RFD85175x37--85100-106542.10.57
RFD80130x30-352003808095-105572.7-3.10.77-.80
RFD60175x40-501503006065-72552.1-2.40.57-.60
RFD40280x60-70902004054-60561.34-1.55.38-.40
RFD25600x100-105421402534-3857.75-.80.22-.23
RFD20630x125-130421251722-2653.75-.85.20-.22
RFD15720x140-150351101516-2052.65-.70.15-.18
Mesh count per inchWire diameter inchesAbsolute filter rating micronsNominal filter rating microns
8x85.014x.0126300-320310
12x64.024x.0165260-280250
14x88.020x.013255-275250
20x150.0098x.007155-185120
24x110.015x.010115-128110
30x150.009x.00790-10590
40x200.007x.005570-8070
50x250.0055x.004552-5755
80x400.0049x.002840-4540
Mesh count per inchWire diameter inchesAbsolute filter rating micronsNominal filter rating microns
20x250.0098x.0079100-118100
30x360.0098x.006095-10590
40x560.0070x.004075-8365
80x700.0040x.003035-3835
200x600.0024x.001828-3230
165x800.0028x.002025-2925
165x1400.0028x.001616-1815
200x1400.0028x.001612-1410
250x1400.0022x.001611-139
325x2300.0015x.00108-95
500x3600.0010x.00062-31
Meshes per Linear InchWidth of OpeningDiameter of WireOpen Area per CentWeight 100 Sp.ft.
InchesmmInchesmm
16x160.05351.360.0090.22973.38.38
18x180.04661.180.0090.22970.29.48
24x240.03420.8690.00750.19167.28.75
28x280.02820.7160.00750.19162.410.29
30x300.02680.6810.00650.16564.88.35
36x360.02130.5410.00650.16558.710.09
40x400.01850.470.00650.16554.811.29
50x500.01450.3680.00550.12752.610.14
60x600.01220.310.00450.11453.38.13
70x700.01060.2690.00370.09454.96.4
76x760.00950.2410.00370.09451.76.99
80x800.00880.2240.00370.09449.67.39
90x900.00760.1930.00350.08947.87.48
94x940.00710.180.00350.089457.84
105x1050.00650.1650.0030.07646.96.41
120x1200.00580.1470.00250.06447.35.07
165x1650.00420.1070.00190.04847.14.04
200x2000.00340.08640.00160.040646.23.48
230x2300.00290.07370.00140.0356463.06
400x4000.00160.04150.00090.02235.12.9

YKM group deals with all dimensions of Stainless Steel Wire Cloth Mesh screen that are the best suitable for all your woven wire net needs. In a wide range of industries, wire mesh is used since it’s amongst the foremost common materials for plain-woven wire mesh materials besides mild steel and galvanized steel with completely different properties. As a manufacturer, YKM group provides a wide variety of wire cloth like aluminium screen wire mesh, brass, fine metal panels, copper wire net, nickel wire mesh, low carbon and woven mesh with standard sizes and different dimensions like aperture size, weave type & more.

YKM Manufacture and Supply Wire Mesh to UAE, OMAN, KUWAIT, QATAR, BAHRAIN, SAUDI ARABIA, DJIBOUTI and More…

To find out more about head to our website Contact Us Page or contact us today via

Email: [email protected] or Call on +971 6 535 5899
